 TSOP Tray JEDEC Matrix IC Trays |
|||
 | ||||
|
||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TSOP Type I Body + Leads Size |
Quantity Pockets Per Tray |
Matrix Row-Column |
ePAK Reference |
Order TopLine Tray Part Number |
||
| 8 x 13.4mm | 234 | 13 x 18 | eTR0174 | TTRAY8x13.4mm-13x18 | ||
| 8 x 20mm | 156 | 12 x 13 | eTR0175 | TTRAY8x20mm-12x13 | ||
| 10 x 14mm | 160 | 10 x 16 | eTR0296 | TTRAY10x14mm-10x16 | ||
| 10 x 20mm | 120 | 10 x 12 | eTR0353 | TTRAY10x20mm-12x10 | ||
| 12 x 20mm | 96 | 8 x 12 | eTR0167 | TTRAY12x20mm-8x12 | ||
| 14 x 20mm | 96 | 8 x 12 | eTR0271 | TTRAY14x20mm-7x13 | ||
| TSOP Type II Body Size |
Quantity Pockets Per Tray |
Matrix Row-Column |
ePAK Reference |
Order TopLine Tray Part Number |
||
| 10.16 x 18.4mm (0.4"x0.725") |
135 | 9 x 15 | - | T2TRAY10X18.4mm-9x15 | ||
| 10.16 x 20.95mm (0.4"x0.825") |
117 | 9 x 13 | - | T2TRAY10X21mm-9x13 | ||
| 10.16 x 22.22mm (0.4"x0.875") |
108 | 9 x 12 | eTR0337 | T2TRAY10X22mm-9x12 | ||
| 10.16 x 26mm (0.4"x1.02") |
99 | 9 x 11 | - | T2TRAY10X26mm-9x11 | ||
| Optional Features: Specify max temperature: 140°C or 150°C when ordering. Tray color is Black. All trays have ESD properties. | ||||||
| TSOP Tray Coordinates | ||||||
