PC Board Kits Practice & Placement Kits   1. About Practice Kits 2. PC Boards Specs 3. About Fiducial Marks 4. About Solder Paste Artwork 5. Go to Free Solder Paste Artwork   6. Go to Gerber & Placement Data 7. General Kit Information 8. Kit Part Numbering System 9. Complete Kit Catalog (PDF) 10. Acrylic See Through Boards   Click PC Board Number below for more details about Kit Kit Name Main Components PC Board Number QFP Tool QFP Lead Straightening Tool 900000 B-24 Board SIR Test Board 900024 B-25 Board SIR Test Board 900025 B-36 Board SIR Test Board LCC68 900036 FC176 Flip Chip Substrate 176 Bump Flip Chip 204µm 901001 FC88 Flip Chip Substrate 88 Bump Flip Chip 204µm 902001 FC317 Flip Chip Substrate 317 Bump Flip Chip 254µm 903001 FC220 Flip Chip Substrate 220 Bump Flip Chip 204µm 904001 CBGA196 Ceramic Substrate 4x CBGA196 1.27mm pitch 905201 CBGA1089 Ceramic Substrate 2x CBGA1089 1.27mm pitch 905901 FC96 Flip Chip Ceramic Substrate FC96 Flip Chip 457µm 906001 FC96 Flip Chip Substrate FC96 Flip Chip 457µm 907001 FC48 Flip Chip Ceramic Substrate FC48 Flip Chip 457µm 908001 FC48 Flip Chip Substrate FC48 Flip Chip 457µm 909001 Beginner's Throughhole 24 Traditonal Throughhole Components 910001 FC112 Flip Chip Substrate FC112 Flip Chip 152µm 911001 Re-certification by Hand Low Cost Mixed Technology for Re-certification 912001 Multilayer Lead Free Throughhole DIP14 Daisy Chain + Connector + Zero Ohm Resistors + Capillary PTH Test 913001 Mixed Technology 2 Fine Pitch SMD and BGA, Chips and Throughhole 914001 Multipurpose Throughhole Machine Run 900 Plated Throughholes 915001 Multipurpose Throughhole Hand Assembly 900 Plated Throughholes 916001 BGA352-BGA400 Kit BGA352 1.27mm & BGA400 1.5mm (OBSOLETE) 917001 Flip-Chip Glass Underfill 50um Full Array. Pitch 80 ~ 250um 918000 Machine Run Large board 9"x8" chips, BGA, TQFP, TSOP, PLCC 919001 Challenger 1 See new Challenger 2 #928001 920001 µBGA TV46 Tessera µBGA CSP46 0.75mm pitch 921001 µBGA TV74 Tessera µBGA CSP74 (Obsolete) 922001 µBGA TV188 Tessera µBGA CSP188 (Obsolete) 923001 Beginners SMT Simple Kit with PLCC, SOIC, SOT, Chips 924001 SMD Introductory Kit QFP, PLCC, SOIC, SOT, Chips 925001 Practical Hand Kit QFP, PLCC, SOIC, SOT, DIP, chips 926001 Challenger 2 Kit QFP, BGA, PLCC, SOIC, SOT, Chips 928001 Jumbo Chip Kit 0402, 0603, 0805, 1206 chips 929001 Advanced SMD 1 QFP, TQFP, TSOP (Pitch 0.5~1.0mm) 930001 Advanced SMD 2 QFP,TQFP, TSOP (Pitch 0.4~1.0mm) 931001 µBGA TV62 Tessera µBGA CSP62 RAMBUS 0.8mm/1.0mm (Obsolete) 932001 µBGA TV208 Tessera µBGA CSP208 RAMBUS 0.5mm (Obsolete) 934001 Stencil Eval 0.3mm Pitch TQFP, QFP, BGA, TSOP, PLCC 935001 Stencil Eval 0.4mm Pitch QFP, BGA, TSOP, PLCC 936001 BGA256/272 Kit BGA256/272 Pitch 1.27mm 937001 Econo Kit 2 TQFP, SO, DIP, Chips 938001 Econo Kit 3 QFP, PLCC, SO, DIP, Chips + throughhole 939001 Monster Kit See 948001 940001 0.3mm Pitch Kit TQFP168 (obsolete) 943001 Rework Practice 2 QFP, PLCC, SOIC, SOT, chips 944501 PCMCIA LQFP, TSOP, Chips 945001 Universal BGA 1.27/1.5mm BGA for 1.27mm and 1.5mm pitch without daisy-chain 946001 Multiple BGA Daisy-chain Top: BGA196/256/272/352/388   Back: BGA225/352/388 947001T Top 947001B Back BGA Mounting Monster Kit 2 Combines Advanced 930001 and Challenger 2 Kits 928001 948001 0201 / 0401 Kit 0201 chips on top side and 0402 chips on back side of board. Daisy Chain 949001 SABER Array 4-Board array Mixed Technology designed by SMTA fine-pitch, BGA, TSOP, SIR coupon, Wave solder coupons, etc 950001 Multiple CBGA CBGA121,196,256,304,361,625 on FR-4 Board 951001 B-52 SIR Test Cleanliness & Residue Evaluation Test IPC-B-52 Compatible 952001 Visual Placement Inspection Acrylic with sticky surface for BGA 1.27mm and 1.5mm pitch 953001 Visual Placement Inspection Acrylic with sticky surface for µBGA and CSP 0.5mm to 0.8mm pitch 953101 Visual Placement Inspection Acrylic with sticky surface for 0.8mm and 1.0mm BGA 953201 Visual Placement Inspection Acrylic with sticky surface for Flip Chip 204um, 254um and 457um pitch 953401 Visual Placement Inspection Acrylic with sticky surface for Flip Chip Grid Lines 4mil to 20mil 953501 Visual Placement Inspection View of Layers of Typical Visual Boards 953xxx HP Saber Alloy Test Kit 4-Layer SABER PCA OSP 9548xx Die Bond Kit Die Bond to QFN48 Lead Frame with daisy chain 955000 CLGA CLGA239, 334, 383, 559, 608, 944, 1007 with daisy chain 956009 CBGA196 and CBGA625 CBGA196/625 with daisy chain 957001 BGA1225 and BGA1089 BGA1225 & BGA1089 with daisy chain 958001 Glass Underfil 50um, 100um, 125um Simulate Flip Chip Underfill 5mm to 15mm 959001 Machine Diagnostic Kit 3 Machine Diagnotic kits: Speed, Rotational & Fiducials 960001 TSOP32 Kit 9 each TSOP32 0.5mm pitch 960301 Fiducial Evaluation QFP100 with 10 different fiducial marks 961001 BQFP132 BQFP132 25 mils 961301 QFP160 QFP160 0.65mm Pitch 961601 Rotational Placement 360° TSOP, SO, Chips 961801 Assortment QFP 0.4mm to 0.8mm QFP120, QFP160, QFP208, QFP256 962001 QFP208 QFP208 0.5mm Pitch 962101 QFP256 QFP256 0.4mm Pitch 962501 Universal BGA 0.5mm - 0.8mm Universal BGA with non-daisy chain pads for 0.5mm, 0.75mm and 0.8mm pitch 963001 Chip Shooter 0402 / 0603 0402 and 0603 Chips Daisy Chain 964001 Rework Practice 1 QFP, PLCC, SOIC, SOT, chips 965001 BGA169 / 225 Daisy Chain Test BGA169 and BGA225 1.5mm pitch 967001 Chip Shooter 0805 / 1206 0805 and 1206 Chips 968001 Mixed Technology 1 QFP, PLCC, SOIC, Chips, DIP 969601 SMD Bread Board Snaps apart for Prototyping 970500 Sample Display Boards for Show & Tell Parts mounted in plastic case 970000 Not used Internal Use 971 - 972 CCGA1089 - 1.27mm (SRO 35mil) and CCGA1247 - 1.0mm (SRO 33mil) Column Grid Array FR4 Board 973000 BGA1600 - BGA1936 BGA1600 and BGA1936 1.0mm Pitch 974000 QFN Board 20 Different QFN 0.4mm~0.65mm , 3mm ~ 12mm , 8L ~ 80L 975000 BGA256Board 6x BGA256 P=1.0mm 976000 Metcal Rework Practice Board Rework Practice Board 3 977001 See 978000 Rework 3 Kit Rework Practice 3 Kit 978001 NASA Solder Training Board Throughhole Practice Board 979001 01005 / 0201 Chip Daisy Chain Zero Ohm Chip Board 980001 Universal BGA 1.0mm / 0.8mm Universal BGA board for 1.0mm and 0.8mm pitch 981001 Lead Free QFP208 QFP208 with Ni-Pd leads and tin board 982001 Lead Free 0805 / 1206 chips 0805 and 1206 chips with tin terminations and tin board 983001 Lead Free 0402 / 0603 chips Lead Free 0402 and 0603 chips 984001 Lead Free BGA See 947 board 985001 Lead Free BGA and Fine Pitch Lead Free BGAs, QFP, chips 986001 BGA and Fine Pitch HASL Sn/Pb version of 986001 987001 Global Fiducial Only Global Fiducial Only 5.5" x 8" 997001 Throughhole Connector 120-Pin 2X Connectors 1.27mm pitch 990015 990016 Fine Pitch BGA 0.8mm / 1.0mm Pitch BGA676 1.0mm and BGA100 0.8mm pitch 998000 Fine Pitch BGA 0.8mm / 1.0mm Pitch BGA672 1.0mm and BGA100 0.8mm pitch 998101 Obsolete. See 998000 BGA172 - 1.0mm Pitch 12mm 12-Layer Board BGA172 999013 CGA1752 - 1.0mm Pitch 4-Layer Board Column Grid Array 999015 BGA1752 - 1.0mm Pitch 4-Layer Board Ball Grid Array 999016 BGA 15x15mm STAND OFF BOARD Controlled Height For Underfill 999080 BGA 15x15mm STAND OFF FIXTURE Tool for mounting Glass Components 999099 BGA324 - 1.0mm Pitch 23mm BGA Concentric Ring Cleanliness Board 999141 BGA272 - 1.27mm Pitch 27mm BGA Concentric Ring Cleanliness Board 999143 BGA676 - 0.8mm Pitch 23mm BGA Concentric Ring Cleanliness Board 999145 BGA2025 - 0.4mm Pitch 21mm BGA Concentric Ring Cleanliness Board 999147 BGA Substrates Practice Substrates for BGA Semiconductor Manufacturing Equipment BGA Substrates Top of Page    Back To Products    TopLine Home TopLine Corporation 95 Highway 22 W Milledgeville, GA 31061, USA Toll Free USA/Canada (800) 776-9888 International: 1-478-451-5000  •  Fax: 1-478-451-3000 Email: Info ©2025 TopLine. All Rights Reserved.
